High-temperature equipment that can perform firing and carbonization under high vacuum or atmosphere protection according to the selection of the materials to be fired.
| Work area size W×H×L（mm） | 400×400×1000 | 600×600×1500 | 700×700×2000 | |||
| Ultimate vacuum degree（Pa） | 1X10-2 | 1X10-3 | 1X10-2 | 1X10-3 | 1X10-2 | 1X10-3 |
| maximum temperature（℃） | 2400 | 2200 | 2400 | 2200 | 2400 | 2200 |
| temperature uniformity（℃） | ±7.5 | ±7.5 | ±7.5 | ±7.5 | ±7.5 | ±10 |
| Pressure rise rate（Pa/h） | 0.67 | 0.67 | 0.67 | |||
1. Maximum design temperature: 2400℃
2.Long-term use temperature: 2200℃
3. Large loading space and convenient loading and unloading of materials
4. Heating method: high purity graphite heating element
5. Power: multi-zone temperature control, voltage < 50v
6. Furnace door opening and closing method: hinged electric rotary type
7. Incoming and outgoing material mode: special truck loading type
8. High vacuum or protective atmosphere
