Question:What is the maximum loading capacity (weight/volume)? What are the material loading and unloading methods? Are matching crucibles/boats provided as complimentary items? What materials are they made of?

Detailed Answer:

Efficient furnace loading/unloading operations and appropriate tooling fixtures serve as the bridge connecting individual equipment performance with overall production line efficiency. We offer flexible solutions to accommodate diverse production requirements.

I. Loading Capacity and Material Handling Methods

• Maximum Loading Capacity:In our current standard equipment series, themaximum loading volume reaches 1500 liters, and themaximum loading weight reaches 1000 kilograms. For ultra-large requirements, we support special customization.

• Loading and Unloading Methods:We offer three mainstream material handling designs to accommodate different workshop layouts and automation levels:

  1. Top Loading (Overhead Hoisting):Suitable for workshops equipped with overhead cranes or gantries, facilitating the use of lifting tools and offering high space utilization.

  2. Bottom Unloading (Hydraulic Lift):Facilitates integration with downstream processes, enables automated production line operation, and can reduce heat loss.

  3. Horizontal Loading (Side, Lateral Pull-out):Offers intuitive and convenient operation, particularly suitable for loading long products (such as carbon fiber tows or graphite bars).

You can choose the most suitable solution based on your workshop's actual conditions and process requirements.

II. Tooling Fixtures (Crucibles/Boats)

• Material:All supporting tooling we provide, such as crucibles, boats, and support plates, are manufactured fromhigh-purity graphitematerials. This ensures sufficient strength, purity, and thermal stability at high temperatures without contaminating the products.

• Supply Method:Regarding whether tooling is included with the equipment, we adopt a flexible negotiation approach. Typically, during the proposal and quotation stage, we will clearly list the specifications and pricing of the supporting tooling. You can decide based on your needs for a"turnkey solution" or "itemized procurement."We strongly recommend procuring the matching tooling from us to ensure optimal compatibility with the furnace interior dimensions and the process requirements.
