I. Complete Quotation Structure

Our quotation typically includes (but is not limited to) the following main items:

• Main Unit System:Includes all mechanical structures such as the furnace body, frame, furnace door, observation window, and temperature measurement system.

• Heating and Power Supply System:Medium frequency power cabinet, compensation capacitors, induction coil, connecting busbars, etc.

• Vacuum System:Vacuum pump set (mechanical pump, roots pump, etc.), vacuum valves, vacuum piping, vacuum gauge, etc.

• Cooling System:Water chiller unit, plate heat exchanger, water pump, water tank, piping valves, and water temperature, pressure, flow sensors.

• Automatic Control System:PLC, touch screen, low-voltage electrical components, sensors, control cabinet, etc.

• Gas Circuit System:Mass flow controllers, pressure sensors, pneumatic valves, piping, etc.

• Technical Documentation and Training:Operation manual, circuit diagrams, certificate of conformity, etc., as well as on-site training fees.

• Installation and Commissioning Services:Labor costs and travel expenses for our engineers' on-site installation and commissioning.

• Transportation and Insurance:Equipment packaging, transportation costs, and transportation insurance.

• Spare Parts:List of common spare parts and consumables included with the equipment.

•

II. Value of Itemized Quotation

• Transparent Spending:You can see the core cost distribution of the equipment.

• Flexible Adjustment:If you have budget constraints, we can discuss based on the itemized quotation where the most cost-effective adjustments can be made.

• Future Reference:Provides an accurate basis for your future spare parts procurement and maintenance cost calculations.
